KONA Capture, Display, Convert v16.2 86 www.aja.com
Video Input Digital
• 3G-SDI, SMPTE 425
• RGB 4:4:4 12-bit*, YCbCr 4:2:2 10-bit
• 1.5G-SDI, SMPTE 292M
• Single Link HD-SDI YCbCr 4:2:2 10-bit
• 270 Mbps SDI, SMPTE 259M-C
• YCbCr 4:2:2 10-bit, 8-bit
*Bit depth support is application dependent. Check with your software
manufacturer for compatibility.
Video Output Digital
• 3G-SDI, SMPTE 425
• RGB 4:4:4 12-bit*, YCbCr 4:2:2 10-bit
• 1.5G-SDI, SMPTE 292M
• Single Link HD-SDI YCbCr 4:2:2 10-bit
• 270 Mbps SDI, SMPTE 259M-C
• YCbCr 4:2:2 10-bit, 8-bit
*Bit depth support is application dependent. Check with your software
manufacturer for compatibility.
HDR
• SDI: VPID signaling for SDR/HDR Transfer Characteristics, Colorimetry and
Luminance.
Audio Input Digital
• 16-channel 24-bit SDI embedded, 48 kHz synchronous
Audio Output Digital
• 16-channel 24-bit SDI embedded, 48 kHz synchronous
Reference / LTC Input
• Analog Color Black or HD Tri-level sync
• LTC
Electrical Interface
• 2-lane PCIe 2.0
Machine Control
• RS-422, Sony 9-pin protocol
• 9-pin D-connector pinout is as follows:
• 1 GND
• 2 RX-
• 3 TX+
• 4 GND
• 5 No Connection
• 6 GND
• 7 RX+
• 8 TX-
• 9 GND
• Shell GND
