KONA Capture, Display, Convert v16.2 84 www.aja.com
Video Output Analog
• Composite/S-Video (Y/C) (1x BNC/2 x BNC+adapter)
• NTSC, NTSCJ, PAL
• Component (3x BNC)
• HD: YPbPr, RGB
• SD: YPbPr, RGB (component mode)
• SMPTE/EBU N10, Betacam 525 line, Betacam 525J, RGB
• 12-bit D/A, 8x oversampling
• +/- .2 dB to 5.0 MHz Y frequency response
• +/- .2 dB to 1 MHz C frequency response
• 5% 2T pulse response
• <1% Diff Phase
• <1% Diff Gain
• <1% ns Y/C delay inequity
Audio Input Digital
• 16-channel, 16 and 24-bit SDI embedded audio, 48 kHz sample rate,
synchronous
• 16-channel, 16 and 24-bit AES/EBU audio, 48 kHz sample rate, synchronous
(via 8x BNC on optional K3G-Box)
• 8-channel, 16 and 24-bit AES/EBU audio, 48 kHz sample rate, synchronous or
nonsynchronous, internal sample rate conversion (via 4x BNC on breakout
cable)
Audio Output Digital
• 16-channel, 16 and 24-bit SDI embedded audio, 48 kHz sample rate,
synchronous
• 16-channel, 16 and 24-bit AES/EBU audio, 48 kHz sample rate, synchronous
(via 8x BNC on optional K3G-Box)
• 8-channel, 16 and 24-bit HDMI embedded audio, 48 kHz sample rate,
synchronous
• 8-channel, 16 and 24-bit AES/EBU audio, 48 kHz sample rate, synchronous or
nonsynchronous, internal sample rate conversion (via 4x BNC on breakout
cable)
Downstream Keyer
• Supports graphics up to 2K/HD with alpha channel over video, matte or
framebuffer, or framebuffer content over incoming video or matte
• SD to SD Aspect Ratio Conversion
• Letterbox: This transforms SD anamorphic material to a letterboxed image
• H Crop: Will produce a horizontally stretched effect on the image; transforms
anamorphic SD to full frame
• SD Pillarbox: Will produce an image in the center of the screen with black
borders on the left and right sides and an anamorphized image in the center
• V Crop: Will transform SD letterbox material to an anamorphic image
Timecode
• LTC timecode input and output (via 1x BNC each)
Reference Input
• Analog Color Black (1V) or Composite Sync (2 or 4V) or HD Tri-Level Sync (1V)
(via breakout cable or optional K3G-Box)
• Reference input is terminated into 75 ohms when Genlock is set to Ref In on
optional K3G-Box, also terminated on supplied breakout cable.
