KONA Capture, Display, Convert v16.2 73 www.aja.com
Audio Mixer Playback Monitor Mode Screen
Playback Source Selection
Clicking the On checkbox selects the audio for that item for playback to the audio
monitor outputs. Multiple sources can be selected simultaneously.
Main App
If an external application is controlling the KONA, it will be displayed in the Item
Select column and its audio can be selected for playback with the checkbox.
AJA Input
Selects for monitoring the audio being input to KONA.
NOTE: The AJA Input Item Select dropdown selection is linked to the Input Select screen's
Audio Input Select dropdown. Changing the setting on one screen will also
change the setting on the other screen.
In the Item Select column, click on the dropdown and choose from:
• Auto - Automatically selects audio as detected.
• AES/EBU - Digital audio being received on the breakout cable BNCs or
breakout box (not KONA 1).
• SDI Ch 1-16 - The embedded audio being received on the KONA SDI In
connectors.
