KONA Capture, Display, Convert v16.2 13 www.aja.com
UFC Firmware
• Supports SD, HD, and 2K formats
• Supports up/down/cross-conversion
• Does not support 4K/UltraHD video or Audio Monitor mixing
Figure 8. KONA 4 in UFC Mode Control Panel Screen Example
The AJA Control Panel application provides an easy to use graphical user interface
for configuration control. See "AJA Control Panel User Interface" on page 28 for
detailed information.
KONA 1 Features
Figure 9. KONA 1 Card
3G-SDI
Input
3G-SDI
Output
Reference/LTC
Input
RS-422
(9 pin D)
Designed for broadcast, post and ProAV, as well as OEM developers, KONA 1 is a
robust, cost efficient single-channel 3G-SDI 2K/HD 60p I/O card with serial control
and reference/LTC. KONA 1 enables simultaneous pass-thru monitoring during
capture.
