10 GigE IP Mini-Converters SMPTE 2110 IP Transmit/Receive v2.5 11 www.aja.com
Figure 2. IPT-10G2-SDI Connections
2 Channel
Unbalanced
Analog Audio
Input
(RCA Jacks)
Input SDI
Connector 1
Control
LAN
SFP+ Cage for
10 Gbps Ethernet
Lock LED
Ready LED
Link/Act
LED 1
Link/Act
LED 2
SFP+ Cage for
10 Gbps Ethernet
Output SDI
Connector 2
USB Port
+5-16 VDC
Power Input
Reference
Out BNC
Figure 3. Example Workflow Diagram for the IPT-10G2-HDMI
HD Camera or Other
HDMI Source*
10 GigE Switch
PTP Generator
1x HDMI
Ref Out
Ref In
IPR-10G2-HDMI
1x
HDMI
Media Server
HD HDMI
Remote Monitor
Black Burst/
Tri-level sync
based on
PTP clock
HD (up to 60p) Input/Output
Redundant IP feeds
10 GigE
Input/Output
HD (up to 60p)
Redundant
IP Feeds
Figure 4. IPT-10G2-HDMI Connections
2 Channel
Unbalanced
Analog Audio
Input
(RCA Jacks)
Input HDMI
Connector
USB Port
+5-16 VDC
Power Input
Control
LAN
SFP+ Cage for
10 Gbps Ethernet
Lock LED
Ready LED
Link/Act
LED 1
Link/Act
LED 2
SFP+ Cage for
10 Gbps Ethernet
Reference
Out BNC
