IPTR-10G2-Series Mini-Converters SMPTE 2110 IP Tx/Rx v2.5r1 5 www.aja.com
Chapter 1 – Introduction
Overview
AJA IPTR-10G2-Series Mini-Converters are designed for point of use applications
for encoding, transport, reception and decoding of IP based video sources.
Rugged, compact and fanless, the IPTR-10G2-Series Mini-Converters provide
the bridge between Baseband and IP video for a range of applications,
such as sending and receiving video over IP from remote facilities in
post production, source monitoring, digital signage, and video walls.
IPTR-10G2-Series Mini-Converters ease the cost of extensive monitoring
distribution in a facility.
The 10 GigE IP Mini-Converter Transmitters take baseband HDMI or SDI input
and encode the data as SMPTE 2110. The embedded audio associated with the
video stream is also encoded to SMPTE 2110. Alternatively, analog audio can be
encoded and sent with the video stream instead.
The 10 GigE IP Mini-Converter Receivers decode SMPTE 2110 and format the data
for either HDMI or SDI output. The audio associated with the video stream is
extracted, synchronized, and then embedded into the HDMI or SDI signal as well
as output on a stereo analog RCA audio output.
All UltraHD rates (23.98, 24, 25, 29.97, 30, 50) can be received only by the IPR-10G2-
HDMI.
The IPR-10G2-HDMI can provide RGB (rather than YCbCr) to a compatible monitor
if the monitor or other sink device indicates this availability via EDID.
