DRM2 Mini-Converter Rack-Mount Frame Manual v1.0 19 www.aja.com
USB Connections
Below we describe use of USB hubs. USB may also be managed by KVM or KVM
over IP, which are the beyond the scope of this manual.
USB Hub
There is no disadvantage to using a USB hub for Mini-Converters installed in a
DRM2 frame, provided some good practices are employed:
• Use an actively-powered hub (one with an AC/DC adapter; not bus-powered).
• Use a high-quality hub, rated as compliant with USB v2.0 or higher.
• A USB v2.0 cable up to ten foot long may be used for the host computer
connection.
• USB from the hub may also be extended by a suitable type of powered
USB 2.0 (or higher) extender.
Figure 29. Example of a typical powered USB v2.0, 12-port hub
AJA Mini-Config USB Device Select
When using AJA Mini-Config software and a USB hub, all of a DRM2 frame's
connected and powered Mini-Converters may be conveniently accessed from the
device select menu:
Figure 30. Mini-Config device select menu for DRM2 frame with 12 devices
