ENGLISH
4. INSTALLATION
4.1 UNPACKING
• Unpack the carton and take the
appliance and accessories out.
• Check the device after unpacking for
any damage or scratches on it.
• Accessories:
1. Exhaust hose
2. Hose connector
3. Window kit adapter
4. Remote control
5. Water pipe
6. Window kit
7. User manual
FIGURE Nº 2
4.2 Choose your location
■ If tipped more than 45°, allow the unit
to set upright for at least 24 hours
before start up.
■ Place the unit on a rm, level surface
in an area with at least 50cm of free
space around it to allow for proper air
circulation.
■ Do not operate in close proximity to
walls, curtains, or other objects that
may block air inlet and outlet. Keep
the air inlet and outlet free of obsta-
cles.
■ Never install the unit where it could
be subject to:
• Heat sources such as radiators, heat
registers, stoves or other products that
products that produce heat.
• Direct sunlight
• Mechanical vibration or shock
• Excessive dust
• Lack of ventilation, such as cabinet or
bookcase
• Uneven surface
FIGURE Nº 3
4.3 ATTACH THE EXHAUST
HOSE
The air conditioner requires being
vented outside so that the exhaust air
can escape the room which coming
from the appliance contains waste heat
and moisture.
Do not replace or extend exhaust hose
which will result in decreased efciency,
even worse shut down the unit due to
low backpressure.
Step 1: Connect the hose connector to
one end of the exhaust hose.
FIGURE Nº4
Step 2: Connect the windows kit
adapter to the other end of the exhaust
hose.
FIGURE Nº5
Step 3: Extend the adjustable window
kit the length of your window. Connect
the exhaust hose to the window kit.
FIGURE Nº6
Step 4: Close your window to secure
the kit in place. It needs to hold the
windows kit rmly in place, secure the
window kit with duct tape if required. It
is recommended that the gap between
the adapter and the sides of the win-
dow should be sealed off for maximum
efciency. FIGURE Nº7
Step 5: Attach the hose connector to
the exhaust air outlet of unit. FIGURE
Nº8
Step 6: Adjusting the length of the
exible exhaust hose, and avoid bends
in the hose. Then place AC near an
electrical outlet. FIGURE Nº9
Step 7: Adjust the louver at the air
outlet, and then switch on the unit.
