Indoor/Outdoor Unit Installation Drawings
The models adopt HFC refrigerant R32.
For installation of the indoor units,refer to the installation manual which was provided with the units.
(The diagram shows a wall-mounted indoor unit.)
Attention must be paid to
the rising up of drain hose
more than 15cm
Optional parts for piping
A
Non-adhesive tape
Adhesive tape
Saddle (L.S) with screws
Connecting electric cable
for indoor and outdoor
Drain hose
Heating insulating material
Piping hole cover
B
more than
G
C
10cm
D
E
F
Arrangement of piping
directions
G
more than 10cm
Rear left
F
Left
Rear
A
right
more than
Right
30cm
C
Below
more than
20cm
more than 20cm
Fixing of outdoor unit
Fix the unit to concrete or block
The marks from to
A
with bolts (10mm) and nuts
and horizontally.
When tting the unit to wall
surface, roof or rooftop, x
a supporter surely with nails
or wires in consideration of
earthquake and strong wind.
If vibration may affect the
rmly
G
in the gure are the
parts numbers.
The distance between
the indoor unit and the
oor should be more
than 2m.
D
E
more than
60cm
house, x the unit by attaching a
vibration-proof mat.
more than 25cm
AIR OUTLET
AIR INLET
CONNECTING PIPING AND ELECTRICAL WIRING
DRAIN HOSE
4
Compressor(Inside of Unit)
If using the left side drain pipe, make sure the hole is got through.
The above indoor and outdoor units’ picture is just for your reference.
Please be subject to the actual product purchased.
12
