10
1. Click the
“
S
y
s
t
e
m
> Port Setting” in the navigation bar as follows:
Interface data are as follows.
Query Items
Description
State
Enable or disable port
Speed/Duplex
Configure the rate and negotiation status of the port. You can
configure the forced 10M/Half, 10M/Full, 100M/Half,100M/Full
1000M/Full
,
2500M/Full
Flow Control
After it is enabled on both local network and opposite network
devices, the local one will notify the other to stop transmitting
messages in the presence of network congestion. The opposite
one
will
execute the
command
temporarily to ensure zero
message loss.
Off-Disabled reception and transmission of PAUSE frame;
On-Enabled reception and transmission of PAUSE frame;
4
Configuration
4.1
VLAN
VLAN is formulated not restricted to physical locations, which means the hosts in a
same VLAN can be placed at will. As shown below, each VLAN, as a broadcast domain,
divides a physical LAN into logical LANs. Hosts can exchange messages by means of
