4. Web Management
AirLive VH-4GW User Manual
120
2.
Delete:
Delete selected tunnels by checking the “Select” box at the end of
each tunnel list and then clicking on the “Delete” button.
3.
Tunnel:
Check the “Enable” box to activate the tunnel.
4.
Edit:
You can edit one PPTP client tunnel configuration by clicking on the
“Edit” button at the end of each tunnel list.
4.2.3.3.8 PPTP Client Configuration
1.
PPTP Client Name:
The name of this tunnel.
2.
Operation Mode:
Default is “Always on” and other options depend on
product models.
3.
Peer IP/Domain:
The IP address or Domain name of remote PPTP server.
4.
User Name:
The username which can be validated by remote PPTP server.
5.
Password:
The password which can be validated by remote PPTP server.
6.
Default Gateway/Peer Subnet:
You can choose “Default Gateway” option
or “Peer Subnet” option here. When “Default Gateway” is chosen, all traffic
from Intranet of Business Security Gateway goes over this PPTP tunnel if
these packets don’t match the Peer Subnet of other PPTP tunnels. There is
only one PPTP tunnel to own the “Default Gateway” property. However,
when “Peer Subnet” is chosen, peer subnet parameter needs to be filled
and it should be the LAN subnet of remote PPTP server. If an Intranet
packet wants to go to this peer subnet, the PPTP tunnel will be established
automatically.
