4. Web Management
AirLive VH-4GW User Manual
105
4.
Resource:
There are 4 resources can be chosen to control in the QoS rule.
They are “Bandwidth”, “Connection Sessions”, “Priority Queues” and “Dif
fServ Code Points”.
5.
Control Function:
It depends on the chosen resource. For “Bandwidth”
resource, the control function is “Set MINR & MAXR”. For “Connection
Sessions”, the control function is “Set Session Limitation”. For “Priority
Queues”, it is “Set Priority”. However, for “DiffServ Code Points”, it is “DSCP
Marking” and you need specify the DSCP value additionally.
6.
QoS Direction:
Select the traffic direction to be applied for this rule.
7.
Sharing Method:
If you want to apply the value of control setting on each
selected host in the “Group”, you need to select “Individual Control” for
Sharing Method. On the other hand, if the value of control setting wants to be
applied on all selected hosts in the “Group”, you need to select “Group
Control”. For example, you define Control Function as “Set Session Limitation”
and the limited sessions are 2000 sessions. You also define Sharing Method
as “Individual Control”. Then, that means the maximum connection sessions of
each selected host can’t exceed 2000 sessions. On the contrary, changing to
“Group Control”, it means that group of client hosts totally can’t use over 2000
connection sessions.
Direction
IN
For Inbound data
OUT
For Outbound data
BOTH
Inbound and Outbound
