Interface data are as follows
Configuration Items Description
State The port No. to configure attributes
Port Enable STP or not
State In Long mode and Short mode
Path Cost Enter the path cost value of the interface Use IEEE 802.1t
Standard with the value ranging from 0 to 200,000,000
Priority Select the port priority with smaller value representing higher
priority.
Interface priority affects the role of the interface on the specified
MSTI. On different MSTI, users can configure the priorities for
a same interface. As a result, flow of different VLANs can be
forwarded along physical links to achieve VLAN load sharing.
Description: MSTP will recalculate the interface role and migrate
its state when its priority changes.
Edge Port Rather than another switch or network segment, the edge port
should be connected directly to user terminals. It can quickly
transit to the forward state since topology changes create
no loops. An edge port under configuration can be quickly
transitioned to forward state by STP. To achieve this, it is
recommended that Ethernet ports connected directly to user
terminals should be configured as edge ports.
BPDU Filter Enable BPDU Filter or not
BPDU Guard
Enable BPDU Guard or not. Unchecked by default. If BPDU
Guard is enabled, the device will shut down the interfaces
receiving BPDU and notify the NMS. Such interfaces can only be
restored manually by network administrators.
Point-to-Point Select enabled, shutdown, and auto modes.
Auto mode: it indicates the connect state between the default
auto inspection and point-to-point links.
Enabled mode: it indicates the specific port is connected to the
point-to-point links.
Shutdown mode: it indicates the specific port fails to connect the
point-to-point links.
2. Fill in corresponding configuration items.
3. “Apply” and finish.
82
