15.2 IPv4 ACL
IPv4-based ACL (Basic IP ACL) formulates rules as per the source IP address of
packets only. ACL ID ranges from 100 to 999.
Advanced IP ACL Rules are made according to the packets’ source/destination IP address,
protocol type carried by IP, and Layer 3 or 4 info such as protocol characteristics. ACL ID
ranges from 100 to 999.
Instructions
1. Click on the “ACL > IPv4 ACL” in the navigation bar as follows.
Interface data are as follows
Configuration Items Description
ACL Name Name the IPv4 ACL rules
2. Click on the “ACL > IPv4 ACE” in the navigation bar, “Add” the ACL Name as
follows:
Interface data are as follows
Configuration Items Description
ACL Name ACL rule list is made based on IPv4 ACL configuration.
3. Fill in corresponding configuration items.
160
