Configuration logic: following steps are used to divide the VLAN based on MAC
address.
1. Create a relevant VLAN.
2. Add Ethernet interfaces to the VLAN in a correct way.
3. Connect the VLAN with the MAC addresses of PC1, 2 and 3.
Data preparation: following data should be prepared for the configuration.
instance:
⚫ Set GE1 PVID of 100 on the switch.
⚫ Set GE1 to access VLAN10 in the Untagged way on the switch.
⚫ Set GE2 to access VLAN10 in the Tagged way on the switch.
⚫ Set the Switch A interface by default, namely all interfaces will be added to VLAN1
in an Untagged way.
⚫ Connect the MAC addresses of PC1, 2 and 3 with VLAN10.
Draw a networking diagram for VLAN division based on MAC addresses:
Instructions:
1. Create a VLAN to recognize the VLANs where employees belong. Click the
“VLAN > VLAN > Create VLAN” in the navigation bar, add VLAN10 to the VLAN
Creating List on the right, “Apply” and finish as follows:
