55
Interface data are as follows.
Configuration Items
Description
Port
Port list
Mode
VLAN mode of port
Membership
The port is the attribute of VLAN ID and VLAN:
Forbidden: do not forward the VLAN message
Excluded: the port out of the VLAN
Tagged: The Tagged member of the VLAN
Untagged: The Untagged member of the VLAN
PVID: whether the VLAN is the port PVLAN
7.1.4 Port Setting
Trunk configuration. Connected with other switches, Trunk interfaces mainly connect
trunk links to allow the VLAN frames to flow through. IEEE 802.1q is the encapsulation
protocol of Trunk link and considers the formal standard for Virtual Bridged Local Area
Networks. It changes the frame format of Ethernet by adding a 4-bit 802.1q Tag
between the source MAC address field and the protocol field.
802.1q frame format
