186
Interface data are as follows.
Configuration Items
Description
ACL Name
ACL rule list is made based on IPv4 ACL configuration.
Sequence
IPv4 ACL ranges from 1 to 2,147,483,647.
Action
ACL actions are divided into “Permit” or “Deny”, as well as
“Shutdown”.
Protocol
It is required to select the protocol type such as ICMP, TCP
and UDP. Select “Any” to represent any protocol.
Source IP
Enter the source IP and mask of ACL rules. Select “Any” to
represent any source IP.
Destination IP
Enter the destination IP and mask of ACL rules. Select “Any”
to represent any destination IP.
Type of Service
Enter the service type of ACL rules, such as DSCP (0-63)
and IP priority (0-7). Select “Any” to represent any service
type.
Source Port
Enter the source port of ACL rules, such as single port No. or
range segment (0-65,535). Select “Any” to represent any
source port.
Destination Port
Enter the destination port of ACL rules, such as single port
No. or range segment (0-65,535). Select “Any” to represent
any destination port.
TCP Flags
Enter the TCP flags of ACL rules, such as URG, ACK, PSH,
RST, SYN, FIN, with the actions such as “Set”, “Unset” and
“Don’t care”.
ICMP Type
Enter the ICMP message type of ACL rules. Select “Any” to
represent any ICMP type.
ICMP Code
Enter the ICMP Code value of ACL rules. Select “Any” to
represent any field value.
3. “Apply” and Finish as follows.
