184
15.2 IPv4 ACL
IPv4-based ACL (Basic IP ACL) formulates rules as per the source IP address of
packets only. ACL ID ranges from 100 to 999.
Advanced IP ACL Rules are made according to thepackets’ source/destination IP
address, protocol type carried by IP, and Layer 3 or 4 info such as protocol
characteristics. ACL ID ranges from 100 to 999.
Instructions
1. Click on the “ACL > IPv4 ACL” in the navigation bar as follows.
Interface data are as follows.
Configuration Items
Description
ACL Name
Name the IPv4 ACL rules
2. Click on the “ACL > IPv4 ACE” in the navigation bar, “Add” the ACL Name as follows:
Interface data are as follows.
Configuration Items
Description
ACL Name
ACL rule list is made based on IPv4 ACL
configuration.
