AirLive ONU-10XG(S)-1004-10G User Guide
4
LAN1-5
The silver LAN1 is 10GE port and the yellow LAN2-5 are 1GE port.
Connect PC or other devices to GE port by Cat5 cable, RJ-45
connector and connect to 10GE port by Cat6a cable, RJ-45 connector.
PON
Connect to OLT by SC type fiber connector, single mode optical fiber
cable.
RST
Press RST button over 10 seconds, ONU restores factory default and
reboots.
USB 3.0
External USB port, connect to USB storage device.
Indication Panel
Figure 1-5-2: Indication panel
Name
Status
Function
PWR
On
Device is powered up.
Off
Device is powered down.
PON
On
Device is registered to PON system.
Off
Device is not registered to PON system.
Blink
Device is registering.
LOS
Off
Device has received optical signal.
Blink
Device does not receive optical signal.
WAN
On
WAN connection is up.
Off
WAN connection is down.
Blink
Data passing WAN connection.
