AirLive ONU-10XG(S)-1004-10G User Guide
17
Figure 3-3-2:WAN config
Parameters
Illustration
Connection Name
This is the list table of WAN connection name. If you want to
create a new WAN connection, please select “Add New Wan” and
input other parameters at the same time and then click “Submit”
button. If you want to edit WAN connection, please select the wan
connect name you want to edit and change parameters and then
click “Submit” button. If you want to delete one connection, please
select the wan connection you want to delete and then click
“Delete” button.
Mode
Bridge: The LAN ports you have selected in this WAN connection
and PON port are in the bridge mode.
Route: The LAN ports you have selected in this WAN connection
and PON port are in the route mode.
IP Version
IPv4: WAN connections use IPv4 protocol.
IPv6: WAN connections use IPv6 protocol.
IPv4 / IPv6: WAN connections use both IPv4 and IPv6 protocol.
IP Mode
DHCP: Automatically obtain an IP address from your ISP
Static: Set the IP address manually
PPPoE: Select this option if your ISP uses PPPoE
Enable VLAN
unchecked: In this wan connection, the packets transmitted by the
PON port without VLAN tag.
checked: In this wan connection, the packets transmitted by the
