Je bekijkt pagina 79 van 201
79
Interface data are as follows.
Configuration
Items
Description
MSTI
Select the instance for configuration through the drop-down box in
the upper left.
Port
Select the port to be configured by users
Path Cost
Enter the path cost value of the interface Use IEEE 802.1t Standard
with the value ranging from 0 to 200,000,000
Priority
Select the port priority with smaller value representing higher priority.
Interface priority affects the role of the interface on the specified MSTI.
On different MSTI, users can configure the priorities for a same
interface. As a result, flow of different VLANs can be forwarded along
physical links to achieve VLAN load sharing.
Description: MSTP will recalculate the interface role and migrate its
state when its priority changes.
Port Role
3 types of root ports, namely specified port, backup port and disabled
