77
state by STP. To achieve this, it is recommended that Ethernet ports
connected directly to user terminals should be configured as edge
ports.
BPDU Filter
Enable BPDU Filter or not
BPDU Guard
Enable BPDU Guard or not. Unchecked by default. If BPDU Guard is
enabled, the device will shut down the interfaces receiving BPDU and
notify the NMS. Such interfaces can only be restored manually by
network administrators.
Point-to-Point
Select enabled, shutdown, and auto modes.
Auto mode: it indicates the connect state between the default auto
inspection and point-to-point links.
Enabled mode: it indicates the specific port is connected to the
point-to-point links.
Shutdown mode: it indicates the specific port fails to connect the
point-to-point links.
2. Fill in corresponding configuration items.
3. “Apply” and finish.
9.3 MST Instance
A switching network is divided into multiple domains by MSTP, with independent
spanning trees formed within each domain. Each Spanning Tree is called a MSTI (Multiple
Spanning Tree Instance), and each domain is called a MST Region: Multiple Spanning
Tree Region).
Description:
An instance is a group of VLANs that reduces communication cost and resource
utilization rate. Each instance, independently calculated with topology, can balance the
load. VLANs with the same topology can be mapped to a same instance, and they are
forwarded according to the port state in corresponding MSTP instances.
In simple terms, mapped to the specified MST instance, one or more VLANs are
distributed to a spanning tree at a time.
Instructions:
1. Click the “Spanning Tree > MST Instance” in the navigation bar, “Edit” the selected
spanning tree instances to be configured as follows:
