76
Interface data are as follows.
Configuration
Items
Description
Port
The port No. to configure attributes
State
Enable STP or not
Path Cost
Enter the path cost value of the interface Use IEEE 802.1t Standard
with the value ranging from 0 to 200,000,000
Priority
Select the port priority with smaller value representing higher
priority.
Interface priority affects the role of the interface on the specified
MSTI. On different MSTI, users can configure the priorities for a same
interface. As a result, flow of different VLANs can be forwarded along
physical links to achieve VLAN load sharing.
Description: MSTP will recalculate the interface role and migrate its
state when its priority changes.
Edge Port
Rather than another switch or network segment, the edge port
should be connected directly to user terminals. It can quickly transit
to the forward state since topology changes create no loops. An
edge port under configuration can be quickly transitioned to forward
