65
7.6 GVRP
GVRP VLAN registration protocol is an application of general attribute registration
protocol, which provides 802.1Q compatible VLAN pruning function and dynamic VLAN
establishment on 802.1Q trunk port trunk port.
GVRP switches can exchange VLAN configuration information with each other, cut
unnecessary broadcast and unknown unicast traffic, and create and manage VLAN
dynamically on switches connected through 802.1Q trunk.
GID and GIP are used in GVRP, which provide the general state mechanism
description and information dissemination mechanism for GARP based applications
respectively. GVRP only runs on 802.1Q trunk links. GVRP cuts off the trunk link so that
only the active VLAN is transmitted on the trunk connection. Before GVRP adds a VLAN
to the trunk line, it first receives the join information from the switch. GVRP update
information and timer can be changed. The GVRP ports have a variety of operating
modes to control how they tailor VLANs. GVRP can dynamically add and manage VLAN
for VLAN database
GVRP supports the propagation of VLAN information between devices. In GVRP,
the VLAN information of a switch can be configured manually, and all other switches in
the network can dynamically understand the VLANs. The terminal node can access any
switch and connect to the required VLAN. In order to use GVRP, a GVRP compatible
network interface card (NIC) should be installed. GVRP compatible NIC can be
configured to join the required VLAN, and then access to a GVRP enabled switch. The
communication connection between NIC and switch is established, and VLAN
connectivity is realized between NIC and switch.
7.6.1 Property
Global and port configuration
Instructions:
1. Click the “VLAN > GVRP > Property” in the navigation bar as follows.
