54
VLAN2 to operate Voice VLAN securely, which allows only Voice Data to flow through. IP
telephony transmits Untagged voice flow to GE1, the ingress Trunk port. Users must
customize an OUI (0011-2231-05e1) and configure the Voice VLAN networking diagram
in automatic mode.
Instructions:
1. Create a VLAN to recognize the VLANs where employees belong. Click the “VLAN >
VLAN > Create VLAN” in the navigation bar to add VLAN 2 to the VLAN list on the right.
“Apply” and finish:
2. Configure the Ethernet interface GE1 of Switch A in Hybrid mode. Click the “VLAN >
VLAN > Port Setting” in the navigation bar, “Edit” GE1 in Hybrid mode:
