46
Interface data are as follows.
Configuration Items
Description
VLAN ID
It is required to select an ID ranging from 1 to 4,094. For
example, 1-3,5,7 and 9. LAN 1 is the default, which won’t be
repeated in another new VLAN.
Name
It is optional to modify the VLAN description as required.
7.1.2 VLAN Configuration
There are two methods. One is to add multiple ports under a single VLAN. The other
is to add a port to multiple VLANs. They are configured according to different purposes.
Instructions for the first method to add the current port to a specified VLAN
1. Click the “VLAN > VLAN > VLAN Configuration” in the navigation bar, select the VLAN
ID on the upper left, and then click the port info as follows:
Interface data are as follows.
Configuration Items
Description
VLAN
VLAN ID to be configured
Port
Port list
Mode
VLAN mode of port
