26
Interface data are as follows
Configuration
Items
Description
Port
Port list
Description
Port alias
State
Enable or disable port
Speed
Configurable automatic negotiation with mandatory states of 10
Mb, 100 Mb, 1000Mb, and 2500Mb. Ethernet electrical interfaces
can use interface speeds including 10 Mbit/s and 100 Mbit/s, and
can be selected according to needs.
Duplex
Configurable auto negotiation with full or half duplexes.
Flow Control
After it is enabled on both local network and opposite network
devices, the local one will notify the other to stop transmitting
messages in the presence of network congestion. The opposite
one will execute the command temporarily to ensure zero
message loss.
Disable-Disabled reception and transmission of PAUSE frame;
Enable-Enabled reception and transmission of PAUSE frame;
Auto negotiation-Negotiate PAUSE frame with opposite network
devices automatically.
3. Select the optical port that needs to be configured, then click the modify button to
enter the modification page:
