200
19.5.4 Alarm
RMON alarm management monitors specific alarm variables, such as port statistics.
An alarm event occurs when the value of monitored data exceeds the defined threshold
in the corresponding direction, which will be treated according to the prescribed
treatment mode. Event definition is realized in event group. After the user defines the
alarm entry, the system will process as follows: The alarm-variable defined by sampling-
time should be sampled and the value should be compared with the threshold. For higher
threshold, the corresponding event will be triggered.
1. Click the “Management > RMON > Alarm” in the navigation bar as follows.
Interface data are as follows.
Configuration Items
Description
Entry
Serial No. of alarm groups
Port
Enter the ports to be counted
Counter
Sample parameters of alarms
Interval
Sampling interval ranges from 1 to 2,147,483,647 with the unit
of second. 100s by default.
Sampling
Sample types: Absolute and Delete
