74
Items
Port
The port No. to configure attributes
State
Enable STP or not
Path Cost
Enter the path cost value of the interface Use IEEE 802.1t Standard
with the value ranging from 0 to 200,000,000
Priority
Select the port priority with smaller value representing higher
priority.
Interface priority affects the role of the interface on the specified
MSTI. On different MSTI, users can configure the priorities for a
same interface. As a result, flow of different VLANs can be
forwarded along physical links to achieve VLAN load sharing.
Description: MSTP will recalculate the interface role and migrate its
state when its priority changes.
Edge Port
Rather than another switch or network segment, the edge port
should be connected directly to user terminals. It can quickly transit
to the forward state since topology changes create no loops. An
edge port under configuration can be quickly transitioned to
forward state by STP. To achieve this, it is recommended that
Ethernet ports connected directly to user terminals should be
configured as edge ports.
BPDU Filter
Enable BPDU Filter or not
BPDU Guard
Enable BPDU Guard or not. Unchecked by default. If BPDU Guard is
enabled, the device will shut down the interfaces receiving BPDU
and notify the NMS. Such interfaces can only be restored manually
by network administrators.
Point-to-Point
Select enabled, shutdown, and auto modes.
Auto mode: it indicates the connect state between the default auto
inspection and point-to-point links.
Enabled mode: it indicates the specific port is connected to the
point-to-point links.
Shutdown mode: it indicates the specific port fails to connect the
point-to-point links.
2. Fill in corresponding configuration items.
3. “Apply” and finish.
9.3 MST Instance
A switching network is divided into multiple domains by MSTP, with independent
spanning trees formed within each domain. Each Spanning Tree is called a MSTI
(Multiple Spanning Tree Instance), and each domain is called a MST Region: Multiple
Spanning Tree Region).
Description:
