Access: port in this mode serves as the only member of
VLAN
Trunk: port in this mode serves as the only Untagged
member of PVID and the Tagged member of VLANs
Tunnel: Port Q-in-Q VLAN
PVID
Port native VLAN
Accept Frame Type
Message types received by ports
All: all messages
Tag Only: only Tagged messages will be received
Untag Only: only Untagged messages will be received
Ingress Filtering
A switch to decide to filter VLAN messages excluded at
the port
Uplink
Whether in uplink mode or not
TPID
Identification No. of VLAN Tag
7.2 Voice VLAN
Traditionally, ACL (Access Control List) will be applied to distinguish Voice Data and
QoS (Quality of Service) will be used to ensure transmission quality, thus enhancing the
priority. In order to simplify user configuration and facilitate voice flow management,
Voice VLAN emerges. Enabled interface judges whether it is Voice Data flow or not
according to the source MAC address field accessing the interface data flow. The
message in the source MAC address is the Voice Data flow, which confirms to the OUI
(Organizationally Unique Identifier) of the voice devices that are configured by the
system. The interfaces receiving Voice Data flow will automatically transmit to Voice
VLAN, thus simplifying user configuration and Voice Data management.
OUI of Voice VLAN
OUI represents a MAC address field. Its address can be calculated based on the 48-
bit MAC address and the corresponding bit of mask. The number of bits of ingress MAC
address and matching OUI is determined by the length of the all “1”-bit in the mask.
For example, if the MAC address is 1-1-1 and the mask is FFFF-FF00–0000, the result of
execution and calculation of MAC address and corresponding mask, namely OUI, will be
0001–0000–0000.
If the first 24 bits of the ingress MAC address are matched with those of OUI, the
enabled Voice VLAN interface identifies the data flow and the ingress device as the
Voice Data flow and voice device respectively.
Voice VLAN is divided for user Voice Data flow. Voice VLANs are created to
connect the interfaces linked with voice devices to transmit the Voice Data inside in a
centralized way.
Voice Data and non-Voice Data often exist in the same network. Voice Data needs
a higher priority than other business data during transmission to reduce the possible
delay and packet loss.
