-4-
Userguide for AirDual-AC12, AWOD-12ACi, AWOD-30AXi
1.5
Product Specification AWOD-30AXi
Model AWOD-30AXi
Device Interface
• Main Chip: Qualcomm IPQ5018
• Flash: NOR 8MB + NAND 128MB
• RAM:512MB
• Standard: IEEE802.11ax, IEEE802.11ac, IEEE802.3,
IEEE 802.11n, IEEE 802.11a ,802.11b, 802.3at,
802.3az
• Frequency: 5.150GHz-5850GHz/2.4GHz to
2.484GHz
• Channel: CH36 ~CH165/CH1-13
(Country depended)
• Modulation: DL/UL-OFDMA modulation, Seamless
Roaming
• Data Rate: 3000Mbps (2.4Ghz 600Mbps, 5.8Ghz
2400Mbps)
• RF Output Power: ≤ 27+2dBm (500mW)
• Antenna: 8dBi Omni Antenna
• WAN: 1 * 10/100/1000Mbps RJ-45 WAN Port,
support IEEE 802.3af 48V PoE in
• LAN Console: 1 * 10/100/1000Mbps RJ-45
Console Port
• Reset Button: 1 * Reset Button, Press 10 seconds,
the device will revert to factory default settings.
• LED Light: SYS, WAN, 2.4G, 5.8G
• Power Consumption: <24W
• Water-proof Level: IP67
Firmware Function
Control
• Operation Mode: Wireless AP, Gateway, WiFi Repeater
• Dynamic IP/Static IP/PPPoE/L2TP(Dual Access)
/PPTP(Dual Access)
Wireless
• SSID broadcast, SSID hide
• Multiple SSID up to 8
• Firewall: DoS, SPI Firewall, IP, MAC, URL filter, IP
and MAC Address Binding
• WiFi timed on/off
• Multicast acceleration
• VPN pass through
• DDNS, Port Forwarding, DMZ Host
• Security: OPEN, WPA, WPA2, WPA-PSK, WPA2-PSK,
WPA3
• Support RF power adjustable based on
environment
• Max Users: 160
Network Function
• Tag VLAN setting based on SSID
• DHCP server
Device Management
• Backup the configuration information
• Restore the configuration information
• Reset to factory default settings
• Device reboot: reboot immediately or timed reboot
• Firmware upgrade
• Time management: including system time and time
synchronization
• System log
• Support WEB GUI management
• Support Cloud remote management (AP Mode)
Multiple Language
• English
ESD Protection
• ESD: Air discharge: ± 8KV, Contact discharge: ± 4KV
Environment
• Operating temperature: -30°C ~ +70°C
• Storage Temperature: -40°C ~ +70°C
• Storage Humidity: 5% ~ 95% (non-condensing)
• Enclosure: IP67
Standard package of switch
• Product size:
30.3cm x 18cm x 8.7cm (L*W*H)
• Package size:
TBD cm(L*W*H)
• Package content: TBD
1 x AWOD-30AXi, PoE Injector, Install Accessory,
LAN Cable, User Manual
Ordering information
• AirLive AWOD-30AXi
Wi-Fi 6 AX3000 Gigabit Outdoor AP
