-10-
Userguide for AirDual-AC12, AWOD-12ACi, AWOD-30AXi
Chapter 4. Configure the CPE
4.1
Main Home Page.
The below web GUI and the topology used in this guide uses the inWall-U618AX/AirDual-AC12 as an example.
It is easy to configure and manage the AP with the web browser. The default setting of the CPE is AP Mode.
The default setting for operation is FAT mode, to view the FIT mode please see chapter 5.
Object
Description
Mode
Shows the current mode status, AP or Gateway mode.
Fat AP/ Fit AP
Switch between Fat AP and Fit AP mode. (Fit mode is used with WLAN
-64/128GM
controller). The Fat and Fit mode is only available in AP Mode not Gateway Mode.
Device Info
Shows the CPU and Memory usage.
Device Description
You can enter the device description.
Flow (2.4/5G Wi-Fi) bps
Shows the Upstream/Downstream graph, select either 2.4G or 5Ghz
LAN Info
Shows the device IP mode, LAN IP, Subnet, Gateway and MAC address.
Wi-Fi Information
It shows the Wi
-Fi status, SSID, Channel, Encryption, MAC address
Hardware accelerate
Only in Gateway Mode.
Version
Shows the current device firmware version.
Reboot and Password Change:
Click on the Green icon with the 4 squares in the top right corner and a pulldown menu will appear.
To change the Password, click on the lock icon and enter your new Password.
To Reboot the CPE, click on the orange icon
