User Manual of AirMax5X II
1.4 Product Specifications
Model Name
AirMax2 II AirMax5X II
Description
AirMax5X II: 5.8GHz 802.11n 300Mbps Outdoor Wireless CPE
AirMax2N: 2.4GHz 802.11n 300Mbps Outdoor Wireless CPE
Hardware Features
Interfaces
Wireless IEEE802.11 a/n, 2T2R Wireless IEEE 802.11a/b/n, 2T2R
PoE: 1 x 10/100BASE-TX, auto-MDI/MDIX, Passive PoE PD
LAN: 1x 10/100BASE-TX, auto-MDI/MDIX
Antennas
Built-in 8dBi directional antenna with
dual polarization
Built-in 14dBi directional antenna with
dual
polarization
Button
Reset/Pair button, WiFi Mode Switch
Dimensions
26.19*8.82*5.82 cm
Weight
405g
Power Requirements
48V Passive PoE
Power Consumption
< 13W
Wireless Interface Specifications
Standard
IEEE 802.11b/g/n
IEEE 802.11i
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x flow control
IEEE 802.11a/n
IEEE 802.11i
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x flow control
Media Access Control
CSMA/CA
Modulation
802.11b/g/n: OFDM (BPSK/ QPSK/
16QAM/ 64QAM)
802.11b: DSSS (DBPSK/ DQPSK/
CCK)
802.11a/n: OFDM (BPSK/ QPSK/
16QAM/
64QAM)
Frequency Band
FCC: 2.412~2.462GHz
ETSI: 2.412~2.472GHz
FCC: 5.180~5.240GHz, 5.745~5.825GHz
ETSI: 5.180~5.700GHz
Operating Channels
FCC: 1~11 Channels
ETSI: 1~13 Channels
FCC:
36, 40, 44, 48, 149, 153, 157,
161,
165
(9 channels)
ETSI: 36, 40,
44, 48, 100, 104, 108,
112,
116,
132, 136, 140 (16 channels)
5GHz channel list will v
ery in different
countries according to their
regulations.
Max. Transmit Power
(dBm)
FCC: up to
20 dBm
ETSI: < 20dBm
(EIRP)
FCC: up to
26dBm
ETSI: < 20dBm
(EIRP)
N
etwork
Mode
Data
Rate
Receive
Se
nsitivit
y
(dBm)
N
etwork
Mode
Data
Rate
Receive
Se
nsitivit
y
(dBm)
802.11b
1Mbps
-95
-6-
