User Manual of AirMax5X II
5.6.4 Security (Port Mapping/Port Forwarding)
Figure 5-41 Port Mapping
The page includes the following fields:
Object
Description
Add
Press
the “Add” button to add the rule in the black or white list
Delete
Press
the “Delete” button to delete the rule
Apply
Press
the “Apply” button to enable/disable the rule
Status
Select
ON (Green) or OFF (Gray) to enable or disable
Rule Name
Enter the
rule name, e.g. Black list
Protocol
Select
TCP, UDP or TCP+UDP
LAN IP
Enter the
IP address that you need for port forwarding
External Port
Enter the
external port range
Internal Port
Enter the
internal port range
Mark
Enter the mark string, or not
