- 31 -
Specifications
Refer to "Operation Manual" for IXG-MK, IXG-DM7(-*).
■ IXG-DM7-BOX
■ IXGW-LC
■ IXGW-GW, IXGW-TGW.En
Mounting Flush wall-mounted
Materials SPCC t1.6
Dimensions 156 mm (6-1/8") [W] × 317 mm (12-1/2") [H] × 60 mm (2-3/8") [D]
Mass Approx. 1.5kg (3.3 lbs)
Power PoE (IEEE802.3af Class 0 standard)
Power consumption Standby 2.1 W, Max. 4.4 W (48 VDC)
LAN Ethernet (10BASE-T, 100BASE-TX), Auto MDI/MDI-X-compatible
Relay 20 relay outputs
Protocol IPv4, IPv6, TCP, UDP, HTTP, HTTPS, IGMP, MLD, SFTP, DHCP, NTP, DNS, TLS
Encryption system TLS1.2, IEEE802.1X
Packet transmission Unicast and Multicast
Operating temperature -10 °C to +50 °C (+14 °F to +122 °F)
Mounting Wall-mounted
Materials Flame retardant resin
Color Gray
Dimensions 210 mm (8-1/4") [W] × 108.5 mm (4-1/4") [H] × 61 mm (2-3/8") [D]
Mass Approx. 310g (0.69 lbs)
Power PoE (IEEE802.3af Class 0 standard)
Power consumption
IXGW-GW: Standby 2.4 W, Max. 2.9 W (48 VDC), IXGW-TGW.E1: Standby 2.8 W, Max. 5.8 W (48 VDC),
IXGW-TGW.E2: Standby 2.8 W, Max. 6.7 W (48 VDC), IXGW-TGW.E3: Standby 2.8 W, Max. 5.1 W (48 VDC)
LAN Ethernet (10BASE-T, 100BASE-TX), Auto MDI/MDI-X-compatible
Public network
connection
specification
IXGW-TGW.E1: LTE(B2/B4/B5/B12/B13/B14/B66/B71), WCDMA(B2/B4/B5)
IXGW-TGW.E2: LTE(B1/B3/B7/B8/B20/B28A), WCDMA(B1/B3/B8), GSM(900/1800)
IXGW-TGW.E3: LTE(B1/B3/B5/B8/B9/B18/B19/B26/B28), WCDMA(B1/B5/B6/B8/B19)
Protocol
IPv4, IPv6, TCP, UDP, SIP, HTTPS, RTP, RTCP, SRTP, SRTCP, IGMP, MLD, SFTP, DHCP, NTP, DNS, MQTT, ICE, DTLS, SDP
Encryption system TLS1.2, IEEE802.1X
Packet transmission Unicast and Multicast
Channel IXGW-GW: 8(Intercom App), IXGW-TGW.En: 8(Intercom App)+1(Phone)
Operating temperature -10 °C to +50 °C (+14 °F to +122 °F)
Mounting Wall-mounted (DIN rail)
Materials Flame retardant resin
Color Black
Dimensions 210 mm (8-1/4") [W] × 108.5 mm (4-1/4") [H] × 61 mm (2-3/8") [D] (62.2mm (2-7/16") [D] with DIN rail)
(Does not include the terminal antennas)
Mass IXGW-GW: Approx. 320g (0.71 lbs) (approx. 350g (0.78 lbs) with DIN rail)
IXGW-TGW.En: Approx. 430g (0.95 lbs) (approx. 540g (1.2 lbs) with DIN rail and terminal antennas)
