21
Communication
SIP Connection Port: 5060
Audio codec: G.711 (μ-law, A-law)
Video codec: H.264/AVC, Motion JPEG
Video Encoder 1 (Intercom Communication)
RTP Video: Start 30000 - End 31000
RTP Audio: Start 20000 - End 21000
Video Encoder 2 (Secondary HD Streaming)
RTP Video: Start 32000 (1-65534) - End 33000 (1-65535)
RTP Audio: Start 22000 - End 33000
Minimum / Maximum Frame Rate (FPS): 1 / 30
Minimum / Maximum Bitrate: 32 / 2048
Minimum / Maximum Resolution (Encoder 2): 320x240 / 1280x960
IXGW-GW Cloud Communication: TLS 1.2 is used to setup encrypted connections with allowed cipher suites
ECDHE-ECDSA-AES128-GCM-SHA256 and ECDHE-RSA-AES128-GCM-SHA256. Certicates are set to
automatically renew with AWS Certicate Manager.
By default, IXG stations use Unicast when placing outbound calls to other stations, but may utilize Multicast
in network environments that would benet from the method. When Paging to more than 50 stations Multicast
is required, and a Multicast address must be set in Support Tool. If Multicast is used, either for calling or when
required for large paging groups, any address in the 224.0.0.0 to 239.255.255.255 range may be used.
Security and Communication (continued)
Addressing
The IXG Series oers Batch IP addressing or can be manually set for each device using IXG Support Tool. Most
IXG stations are set to the same default static IP address, 192.168.1.160. The IXGW-TGW uses 192.168.1.161.
These can be manually changed or set to DHCP during the programming process.
IPv4 (most stations): 192.168.1.160 (1.0.0.0-223.255.255.254)
IPv4 (IXGW-TGW): 192.168.1.161 (1.0.0.0-223.255.255.254)
Subnet Mask: 255.255.255.0 (128.0.0.0-255.255.255.254)
Default Gateway: - (1.0.0.0-223.255.255.254)
IPv6: - (2000::0-3FFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF or
FD0::0-FDFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFFE
IPv6 Default Gateway: - (::FF:0-FEFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFE)
DNS Primary Server IPv4: - (1.0.0.1-233.255.255.254)
IPv6: - (::FF:0-FEFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFE)
Secondary Server IPv4: - (1.0.0.1-233.255.255.254)
IPv6: - (::FF:0-FEFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFE)
NTP IPv4: ntp.jo.aiphone-app.net (1.0.0.0-223.255.255.255 or Hostname)
IPv6: - (::FF:0-FEFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFE or Hostname)
LTE Connection
The IXGW-TGW Mobile App Gateway can be used to connect the IXG system to a 4G LTE mobile network, using
the included SIM card. This connection can be used as a primary network connection for the system, or as a
backup to the ethernet connection. The SIM card also allows for calls to a single phone number on each call from
an entrance station or door station.
Supported Networks: AT&T
®
(requires activation of included AT&T SIM card). Third party SIM cards are not
supported.
