- 4 -

Example

: A system (site) consisting of 1 main and 3 tenant buildings

The GT system consists of up to 8 main buildings and 24 tenant buildings.

Main building:

A control section that functions as a main entrance, guard station, security center, administration ofﬁ ce, etc. A main building includes no

residential/tenant stations. You can call up all of the residential/tenant stations and guard stations from an entrance station or guard station in the

same system (site).

* A station that is not programmed cannot be called.

* Modular type entrance stations cannot be installed in a main building. Only all-in-one type can be used.

Tenant building:

A section of collective housing. A tenant building includes residential/tenant stations, entrance stations and guard stations. You can call up all of

the residential/tenant stations and guard stations from an entrance station in the same tenant building. However, you cannot call stations in

another tenant building.

Tenant building

Main building

(administration ofﬁ ce)

Residential/tenant stations

Entrance station

(all-in-one type only)

Entrance station

(all-in-one type)

Entrance station

(modular type)

Guard station

GT-2C-L/GT-2C

(GT-2H-L/GT-2H)

GT-1C7W-L/

GT-1C7W

GT-1A

GT-1D

GT-1C7-L/

GT-1C7

GT-1M3-L/

GT-1M3

GT-DMB-LVN/

GT-DMB-N

GT-DMB-LVN/

GT-DMB-N

GT-MKB-N

READ THIS BEFORE USING THE STATIONS

SYSTEM CONFIGURATION
