- 11 -
The table below shows the maximum wiring distances between devices.
Wire diameter
Wiring distance
0.65 mm
(22 AWG)
0.8 mm
(20 AWG)
1.0 mm
(18 AWG)
[1]
GT-BC - DP *2 3 m (10') 5 m (16') 5 m (16')
[2]
Entrance station - DP *2 150 m (490') 300 m (980') 300 m (980')
[3]
Entrance station - GT-VBC 150 m (490') 300 m (980') 300 m (980')
[4]
GT-MKB-N - DP *2 150 m (490') 300 m (980') 300 m (980')
[5]
DP *2 - farthest residential/tenant station (includes system with GT-4Z or
GT-1Z)
150 m (490') 300 m (980') 300 m (980')
[6]
GT-VBC - farthest residential/tenant station (includes system with GT-4Z or
GT-1Z) *4
100 m (330') 150 m (490') 150 m (490')
[7]
GT-VBC (MODE: STD / EXP) - GT-VBC (MODE: EXP) 100 m (330') 150 m (490') 150 m (490')
[8]
GT-BC - power supply *3 3 m (10') 5 m (16') 5 m (16')
[9]
GT-VBC - power supply *3 3 m (10') 5 m (16') 5 m (16')
[10]
GT-VBC - farthest GT-MKB-N 100 m (330') 150 m (490') 150 m (490')
[11]
GT-BCXB-N - farthest GTW-LC 150 m (490') 300 m (980') 300 m (980')
[12]
Entrance station - power supply *3 150 m (490') 300 m (980') 300 m (980')
[13]
Entrance station - external door release button 10 m (33') 15 m (49') 15 m (49')
[14]
GT-MKB-N - power supply *3 100 m (330') 150 m (490') 150 m (490')
[15]
GT-MKB-N - JO-DV 30 m (100') 50 m (165') 50 m (165')
[16]
Residential/tenant station/GT-MKB-N - doorbell 5 m (16') 10 m (33') 10 m (33')
[17]
GT-MKB-N - monitor/DVR Coaxial cable 15 m (49')
[18]
Door station - GT-2C-L, GT-2C 50 m (165') 100 m (330') 100 m (330')
[19]
GT-2C-L, GT-2C - farthest GT-2H-L, GT-2H 50 m (165') 100 m (330') 100 m (330')
[20]
GT-2C-L, GT-2C - power supply 25 m (82') 50 m (165') 75 m (245')
[21]
GT-2H-L, GT-2H - power supply 50 m (165') 100 m (330') 150 m (490')
[22]
Residential/tenant station - emergency alarm switch 10 m (33') 15 m (49') 15 m (49')
[23]
GT-4Z - residential/tenant station 30 m (100') 50 m (165') 50 m (165')
[24]
GT-1Z - residential/tenant station 10 m (33') 15 m (49') 15 m (49')
[25]
GT-BCXB-N - power supply *3 3 m (10') 5 m (16') 5 m (16')
[26]
GT-BCXB-N - GT-BC 150 m (490') 300 m (980') 300 m (980')
[27]
GT-VBX - GT-VBC (MODE: EXP) 100 m (330') 150 m (490') 150 m (490')
[28]
Entrance station, GT-MKB-N - GT-BCXB-N 150 m (490') 300 m (980') 300 m (980')
[29]
Entrance station - GT-VBX 150 m (490') 300 m (980') 300 m (980')
[30]
GT-BCXB-N - farthest residential/tenant station (includes system with GT-4Z
or GT-1Z)
150 m (490') 300 m (980') 300 m (980')
[31]
GT-VBX - farthest residential/tenant station (includes system with GT-4Z or
GT-1Z) *4
150 m (490') 300 m (980') 300 m (980')
GT-DB-V, GT-DB-VN, GT-DMB-LVN - (VIGIK) *5 5 m (16') 10 m (33') 10 m (33')
Standard system audio [R1, R2] total wiring distance *1 1650 m (5400') 2500 m (8200') 2500 m (8200')
Expanded system audio [R1, R2] total wiring distance per common line
(maximum 2 trunk lines)
1650 m (5400') 2500 m (8200') 2500 m (8200')
Expanded system audio [R1, R2] total wiring distance per common line
(maximum 4 trunk lines)
1650 m (5400') 2500 m (8200') 2500 m (8200')
Lift control total wiring distance from GT-BCXB-N (including GTW-LC) 1650 m (5400') 2500 m (8200') 2500 m (8200')
GT-RY - residential/tenant station 5 m (16') 10 m (33') 10 m (33')
GT-2C-L, GT-2C - external monitor 1.5 m (5') 3 m (10') 3 m (10')
Entrance station - surveillance camera Coaxial cable 15 m (50')
*1: The wiring distances from a door station to a GT-2C-L or GT-2C are not included in the total wiring distance.
*2: DP = Distribution Point (Not provided by Aiphone except for Europe and North America.)
*3: When powering two or more devices with one power supply, separate the cables near the power supply.
*4: The wiring distance between GT-VBX or GT-VBC (STANDARD) to the farthest residential/tenant station by using GT-VBC (EXPAND) is 300 m (980')
regardless of the wiring method.
*5: A shielded wire is required.
