- 18 -
Mounting positions and image view area3-3
When using the camera module, if the rain hood is attached a portion of it will show up in the camera display.
(with mounting position of 1500 mm (5'))
<Left> <Center> <Right>
<Up> <Center> <Down>
Approx. 700 mm (2' 3")
1500 mm (5') 1500 mm (5') 1500 mm (5')
Approx. 550 mm (1' 9")
Approx. 700 mm (2' 3")
Camera
center
Camera
center
Camera
center
Approx. 2200 mm (7' 2")
Approx. 1800 mm (5' 10")
Approx. 1500 mm
(5')
Approx. 1500 mm
(5')
Approx. 1250 mm
(4' 1")
Approx. 800 mm
(2' 8")
Vertical
Vertical
Horizontal
Horizontal
An area over a range of approx. 170° in a 500 mm (20") radius from the camera
displays. (The display range is a rough estimation and may change due to the
installation environment.)
(
*
1): Zoom view range is approx. 140° at 500mm (20”) distance from the camera.
Mounting position 1500 mm (5')
Approx. 1200 mm (3' 11")
1500 mm (5')
500 mm (20")
500 mm (20")
500 mm
(20")
500 mm (20")
500 mm (20")
500 mm (20")
1300 mm (4' 3")
Approx. 1200 mm (3' 11")
Approx. 170°
Camera center
Camera center
Approx. 2100 mm
(6' 11")
Approx. 1900 mm
(6' 3")
Approx. 900 mm
(3')
Approx. 700 mm
(2' 3")
Mounting position 1300 mm (4' 3")
Wide view
Zoom view
Objects appear smaller due to greater distortion in the surrounding sections
compared to the central section, but a wider area is displayed.
The display range is a rough estimation and may change due to the installation
environment.
The zoom position can be changed.
The default zoom position is center.
Approx. 900 mm (3')
Approx.
1200 mm
(3' 11")
[Vertical center]
Approx. 550 mm
(1' 9")
Approx.
500 mm
(20")
Approx. 900 mm (3')
Approx. 140°
(
*
1)
Approx.
85°
Approx. 900 mm (3')
Approx.
85°
Approx.
500 mm (20")
Approx.
500 mm
(20")
Approx. 900 mm (3')
Approx. 140°
(
*
1)
Approx.
85°
NOTE: Follow the applicable laws and regulations for mounting location.
