AGM Rattler-C V2 handleiding
Handleiding
Je bekijkt pagina 19 van 36
Rattler-C V
2
USER MANUAL 19
2.2.5 NETWORK CONFIGURATION
Connect your phone to the Wi-Fi hotspot of the clip-on, you can configure the
parameters and realize functions of the device.
1. Hold the MENU button
to show the menu.
2. Press
or button to select Network menu item and press the MENU
button to enable or disable Wi-Fi hotspot.
3. Hold the MENU button
to exit a menu.
Open the AGM Connect APP and connect your phone with the device (refer to
Section 2.3). You can view the interface of clip-on on your phone.
NOTE:
When the power is less than 15%, the Wi-Fi hotspot function will be turned off
automatically.
2.2.6 DISTANCE MEASUREMENT
NOTE:
When measuring the distance, keep your hand and the position steady.
Otherwise, the accuracy may be affected.
The device can measure the distance between the target and the observer’s
position.
1. Hold the MENU button
to show the menu.
2. Press
or button to select Measure menu item and press the MENU
button to enter the distance measurement mode.
3. Press
button to enter the target setting interface.
1) Press
or to select the target from Wolf, Bear, Deer, and Custom.
2) Press the MENU button
to set the target height. Press or
buttons to change the number. Each target height preset can be modified
from 0.1 to 9.9 m. Press the MENU button to confirm.
3) Hold the MENU button
to exit target setting.
4. Align the center of the top mark with the top edge of the target. Press the
MENU button
. The top mark blinks and then changes to the bottom mark.
5. Align the center of the bottom mark with the bottom edge of the target. Press
the MENU button
. The bottom mark blinks and then disappears.
6. The right top of the image displays the distance measurement result and the
height of the target.
FIGURE 2-10. DISTANCE MEASUREMENT
