11
Child Lock,
IMPORTANT: The child lock can only be activated when all
the cooking zones are switched o.
To prevent the unwanted use by children, the hob can be
locked.
To lock the hob, simultaneously turn the two left-hand
controls counter-clockwise (Fig. 2-6) and hold until the
symbol appears in the centre of the hob control display
(Fig. 2-7).
Note: [
A ] will ash when locking the hob – this is normal.
Locking the hob will NOT aect the oven; it can still be used.
To unlock the hob, simultaneously turn the two left-hand
controls counter-clockwise and hold until the
symbol
disappears from the centre of the hob control display.
Low Temperature Setting, L1/L2/L3
n
This function should only be used when heating
from cold.
Each cooking area is equipped with 3 low temperature
settings:
• L1 will maintain a temperature of about 44 °C – ideal
for gently melting butter or chocolate.
• L2 will maintain a temperature of about 70 °C – ideal
for keeping food warm, once it has been cooked.
• L3 will maintain a temperature of about 94 °C – ideal
for simmering (bring the pan to the boil and then
select L3 to keep soups, sauces, stews, etc at an
optimal simmer).
The maximum time these settings can be used is 2 hours,
after which the hob will switch o automatically. If required,
you can immediately restart the Low Temperature function
by reactivating L1, L2 or L3. To increase the heat, just turn the
control knob to the required level.
The maximum times for all other power levels are shown in
Table 2.2.
Power Boost Setting, P
All of the induction cooking zones have Power Boost
available, activated by turning the control knob clockwise
until [P ] is shown on the hob control display.
Power Boost allows additional power to be made available for
each of the cooking zones. This is useful to bring a large pan
of water to the boil quickly.
The Power Boost function operates for a maximum of 10
minutes on each zone, after which the power is automatically
reduced to setting 9.
When using the Power Boost function, the cooking zones are
linked.
Fig. 2-8 shows the hob layout. Zones A and B are linked
together as are zones C, D and E.
Table 2.2
Fig. 2-6
Fig. 2-7
Fig. 2-8
Power Level Maximum Operating Time
L1, L2 and L3 2 hours
1 6 hours
2 6 hours
3 5 hours
4 5 hours
5 4 hours
6 1.5 hours
7 1.5 hours
8 1.5 hours
9 1.5 hours
Power Boost 10 minutes
A
B
C
E
D
A & B linked
C, D & E linked
