13. Technical Data

THE COOKER IS CATEGORY: CatII

2H3+.

It is supplied set for group H natural gas. A conversion kit from NG to LP is available for the cooker.

INSTALLER: Please leave these instructions with the user.

DATA BADGE LOCATION: Cooker back, serial number repeater badge below oven door opening.

COUNTRY OF DESTINATION: GB, IE.

Connections

Gas (Rp ½ at rear right-hand side) Electric

Natural Gas

20 mbar

230/400 V 50 HzButane 29 mbar

Propane 37 mbar

See the appliance badge for test pressures.

Dimensions

Model AGA Masterchef Deluxe 110 Dual Fuel

Overall height minimum 905 mm

maximum 930 mm

Overall width 1092 mm

Overall depth

608 mm excluding handles, 694 mm including handles

Minimum height above the hotplate 650 mm

Hotplate Ratings

Hotplate

Bypass

Screw*

Natural Gas G20 20mb L.P. Gas 29 / 37 mb

Injector Injector

Centre burner 57 5.0 kW 165 5.0 kW (364g/h) 107

Large burner 40 3.0 kW 120 3.0 kW (218g/h) 82

Semi Rapide/ small 32 1.70 kW 95 1.70 kW (124g/h) 64

* The valves in this cooker are tted with adjustable bypass screws. The cooker is supplied with the bypass screws set for Natural Gas. For LPG conversion the

bypass screws must be screwed all the way down.

Hotplate energy saving tips Oven energy saving tips

Use cookware with a at base. Cook meals together, if possible.

Use the correct size cookware. Keep the pre-heating time short.

Use cookware with a lid. Do not lengthen cooking time.

Minimise the amount of liquid or fat. Do not open the oven door during the cooking period.

When liquid starts boiling, reduce the setting. Do not forget to turn the appliance o at the end of cooking.

Consumption is based on G30.
