Page 4 of 26
AGA Ludlow & Ellesmere EC5 Revision 1.5 – June 2021
STOVE EFFICIENCY & PERFORMANCE:
Specific Precautions during Assembling, Installing & Maintenance: See installation instructions for more
information
PRODUCT RECYCLING
Product End-of-Life/Recycling: To dispose of the stove after the product life has expired, please observe the
following information
Dispose of the items correctly i.e. separate the parts to be disposed of in material groups
Always dispose of items in a way that is as sustainable as possible and that is in line with the current
environmental protection, reprocessing/recycling and disposal technology
o ALL METAL PARTS TO BE RECYCLED
o ALL GLASS TO BE RECYCLED
o ALL OTHER COMPONENTS TO BE DISPOSE IN A MANNER ACCORDING TO
ENVIRONMENTAL REGULATIONS
MINIMUM DISTANCES TO COMBUSTIBLE MATERIALS:
MINIMUM DISTANCES TO COMBUSTIBLE
MATERIALS:
Minimum Distances to
Combustible Materials (Walls)
Flue Fitted – Main Rear Stove Heat Shield
Fitted as Supplied
Back Wall
Side Wall
Fitted with twin walled insulated flue and rear heat
shield flue collar extension fitted
200mm
500mm
Fitted with single walled flue with rear heat shield flue
collar extension fitted
350mm
550mm
MINIMUM DISTANCES TO NON-COMBUSTIBLE MATERIALS: We recommend a minimum clearance of
100mm to both sides & the back of this stove when being installed next to NON - COMBUSTIBLE
MATERIALS into a fireplace opening constructed of solid brickwork
SPACE HEATING PERFORMANCE AT NOMINAL OUTPUT
Fuel(s)
Primary
Fuel
Seasonal
Efficiency
(%)
(mg/m³)
PM
OGC
CO
NOx
Wood Logs
Yes
74.8
25
109
1375
92
Smokeless Fuel
No
71.5
21.0
13
625
91
PERFORMANCE WHEN OPERATED ON PRIMARY FUEL
Rated Heat Output (kW)
5.0
Nominal Net Efficiency (%)
84.8%
Electrical Consumption Nominal (kW)
N/A
Electrical Consumption Minimum (kW)
N/A
Electrical Consumption Standby (kW)
N/A
Energy Efficiency Index
113
EEI Rating
A+
