AGA Ellesmere EC4 Compact Revision 1.5 – June 2021
Page 3 of 26
ALSO ADDRESSING ECO-DESIGN 2022 AND DEFRA SMOKE EXCEMPTION
GENERAL PRODUCT INFORMATION:
Model Reference:
AGA Ellesmere EC4 – Multi-Fuel Stove
Compact Body Model
Energy Efficiency Class of Model:
A+
Net Efficiencies:
Wood: - 81.1% & Ancit (Smokeless Fuel): 80.6%
Eco-Design Standard 2022 Compliant:
Yes – Approved to the Standard
Direct Heat Output:
4.5kW
Indirect Heating Functionality:
No – Air to Air Convectional & Radiant Heat only – No Hot Water
Type of Heat Output Room Temperature
Control:
Two or more manual stages, no temperature control
Other Control Options:
N/a
DEFRA – Compliant to the Standard:
Yes – Approved to be used in Smoke Exempt Zones/Areas
Hearth Construction – Approved for:
Superimposed 12mm thick - Non-Combustible Hearth such as
(Glass, Steel, Stone or Concrete)
Flue Collar & Flue Pipe Diameter:
Fit 125mm diameter (5.0”) Flue (Single or Twin Walled)
Approved Fuel Types:
Multi-fuel – Dried Wood & Ancit based Smokeless Fuels
Stove Construction:
- 5mm thick - Steel Outer Stove Body & 8mm thick Removable
Lid
- Cast Iron Door & Handle (Handle with Stainless Steel Outer)
- 4mm thick - Ceramic Heatproof Glass
- Vermiculate High Temperature - Firebox Liner
AGA - 3 way Air Management System:
Primary, Secondary & Tertiary Air Inlets via 2 x Controls Knobs
External Air Input kit:
Yes – Optional Extra
Stove Directly Fits onto a Log-Store:
Yes – AGA Log-Store Stand 350mm high - Optional Extra
Top or Rear Flue Exit:
Yes - Top or Rear Flue Exit options built in
Rear Heat Shield:
Yes – Rear Heat Shield Fitted as Standard onto the Rear of the
Stove
Convection & Radiant Heat Sources Outputs:
Yes – Radiant Heat from Both Sides & Front, with Additional
Convectional Heat Ducts from the Rear & Top Outlets
Warranty Period:
5 years –
(Excluding Consumable Items
– see Operating Manual for full
details)
Log Length:
275mm in Length
Sweep Flue through Stove:
Yes – 2 x Removable Top Baffle Plates to Sweep
Grate Type:
Multi-Fuel Grate - Complete with Ash Pan Underneath
Adjustable Bottom Feet for Levelling:
4 x M6 pads fitted to the bottom of feet for adjustment
What’s included with this Stove:
Glove, Ash Pan, Cast Flue Collar, Rear Heat Shield Flue Collar,
Cast Log Retainer & Rear Flue Exit Blanking Plate (Fitted to the
Stove)
Minimum Flue Height/Pascals Rating:
4.6m High and the flue tested at 12 Pascals
STOVE EFFICIENCY & PERFORMANCE:
Efficiency (%)
Energy
Nominal Heat Output (kW)
Fuel Type
Net
Gross
Efficiency
Index
Total
To Space
To Water
CO
(% @13%
Oxygen)
Wood Logs
81.1%
74.4%
108
4.5 kW
4.5 kW
N/a
0.09
Maxibrite
(MSF*)
80.6%
78.6%
N/A
4.6 kW
4.6 kW
N/a
0.08
*MSF = Manufactured Smokeless Fuel
Appliance
Manufacturer:
AGA Rangemaster
Station Road, Ketley
Telford, Shropshire, TF1 5AQ
www.agaliving.co.uk
