30
CHAPTER 7: SPECIFICATIONS
7.1 Display Specications
VA4301 VA5501 VA6501
Panel Panel Type LED-Backlit TFT LCD (IPS
Technology)
LED-Backlit TFT LCD (IPS
Technology)
LED-Backlit TFT LCD (IPS
Technology)
Panel Size 42.5” 54.6” 64.5”
Max. Resolution UHD 3840 x 2160 UHD 3840 x 2160 UHD 3840 x 2160
Pixel Pitch 0.245 mm 0.315 mm 0.372 mm
Brightness 350 cd/m
2
350 cd/m
2
350 cd/m
2
Contrast Ratio 1200:1 1200:1 1200:1
Viewing Angle (H/V) 178°/178° 178°/178° 178°/178°
Display Colour 1.07G 1.07G 1.07G
Response Time 5 ms 5 ms 5 ms
Surface Treatment Anti-Glare Treatment (Haze
1%), 3H Hard Coating
Anti-Glare Treatment (Haze
1%), 3H
Anti-Glare Treatment (Haze
25%), 2H Hard Coating
Frequency
(H/V)
H Freq. 31 kHz-136 kHz 31 kHz-136 kHz 31 kHz-136 kHz
V Freq. 29 Hz-61Hz 29 Hz-61Hz 29 Hz-61Hz
Signal Input HDMI 2.0 x 3 2.0 x 3 2.0 x 3
External
Control
RS232 In 9-Pin D-Sub 9-Pin D-Sub 9-Pin D-Sub
Other
connectivity
USB 2.0 x 1 (Service Port / Media
Playback)
2.0 x 1 (Service Port / Media
Playback)
2.0 x 1 (Service Port / Media
Playback)
Audio Audio Out Stereo Audio Jack (3.5 mm) Stereo Audio Jack (3.5 mm) Stereo Audio Jack (3.5 mm)
Internal speakers 5W x 2 5W x 2 5W x 2
Power Power Supply Internal Internal Internal
Power Requirements AC 100-240V, 50/60 Hz AC 100-240V, 50/60 Hz AC 100-240V, 50/60 Hz
On Mode 54W (On) 78W (On) TBD (On)
Standby Mode < 0.5W < 0.5W < 0.5W
Operating
Conditions
Temperature 0°C-40°C (32°F-104°F) 0°C-40°C (32°F-104°F) 0°C-40°C (32°F-104°F)
Humidity 20%-80% (non-condensing) 20%-80% (non-condensing) 20%-80% (non-condensing)
Storage
Conditions
Temperature -20°C-60°C (-4°F-140°F) -20°C-60°C (-4°F-140°F) -20°C-60°C (-4°F-140°F)
Humidity 10%-90% (non-condensing) 10%-90% (non-condensing) 10%-90% (non-condensing)
Mounting VESA FPMPMI Yes (100 x 200 mm) Yes (200 x 100 mm) Yes (400 x 300 mm)
Security Kensington Security Slot Yes No No
Dimensions Bezel Width 1.5 mm (Top/Left/Right)
19.5 mm (Bottom)
1.5 mm (Top/Left/Right)
21.1 mm (Bottom)
1.9 mm (Top/Left/Right)
20.9 mm (Bottom)
w/o base (W x H x D) 958.4 x 568.5 x 76.7 mm
(37.7” x 22.4” x 3.0”)
1226.8 x 720.3 x 85.3 mm
(48.3” x 28.4” x 3.4”)
1446.7 x 842.9 x 91.6 mm
(57.0” x 33.2” x 3.6”)
with base (W x H x D) 958.4 x 586.7 x 255.8 mm
(37.7” x 23.1” x 10.1”)
1226.8 x 739.5 x 293.2 mm
(48.3” x 29.1” x 11.5”)
1446.7 x 863.9 x 293.2 mm
(57.0” x 34.0” x 11.5”)
Packaging (W x H x D) 1070.0 x 650.0 x140.0 mm
(42.1” x 25.6” x 5.5”)
1360.0 x 840.0 x 160.0 mm
(53.5” x 33.1” x 6.3”)
1600.0 x 1005.0 x 170.0 mm
(63.0” x 39.6” x 6.7”)
Weight w/o base 7.2 kg (15.9 lb) 10.5 kg (23.1 lbs) 16.7 kg (36.8 lbs)
with base 7.3 kg (16.1 lb) 10.7 kg (23.6 lbs) 16.9 kg (37.3 lbs)
Packaging 9.9 kg (21.8 lb) 13.9 kg (30.6 lbs) 24.0 kg (52.9 lbs)
