8
PRODUCT DESCRIPTION
1.4.1 VESA Grid
Model Name VESA Grid
VA4301 100(W) x 200(H)mm
VA5501 200(W) x 100(H)mm
VA6501 400(W) x 300(H)mm
Caution:
To prevent the display from falling:
♦ For wall or ceiling installation, we recommend installing the
display with metal brackets which are commercially available.
For detailed installation instructions, see the guide received with
the respective bracket.
♦ To lessen the probability of injury and damage resulting from fall
of the display in case of earthquake or other natural disaster, be
sure to consult the bracket manufacturer for installation location.
Note:
♦ For the wall-mounting kit, use
M6 screws for VA4301(with a
length at least 10 mm longer
than the thickness of the wall
mount bracket), M6 screws for
VA5501 (with a length at least
9 mm longer than the thickness
of the wall mount bracket) and
M8 screws for VA6501 (with a
length at least 12 mm longer
than the thickness of the wall
mount bracket).
1.4.2 Ventilation Requirements for Enclosure Locating
To allow heat to disperse, leave space between surrounding objects
as shown in the diagram below.
100 mm 100 mm
100 mm
100 mm
VA6501
400mm
300mm
