55
CHAPTER 7: SPECIFICATIONS
7.1 Display Specications
RX-2402
Panel Panel Type LED-Backlit TFT LCD (VA Technology)
Panel Size 23.8"
Max. Resolution FHD 1920 x 1080
Pixel Pitch 0.275 mm
Brightness 300 cd/m²
Contrast Ratio 20,000,000:1 (DCR)
Viewing Angle (H/V) 178°/178°
Display Colour 16.7M
Response Time 5 ms
Surface Treatment Anti-Glare Treatment (Haze 25%), 3H Hard Coating
Frequency (H/V) H Freq. 24 kHz-83 kHz
V Freq. 50 Hz-75 Hz
Input DisplayPort x 1
HDMI 1.4 x 1
DVI 24-Pin DVI-D x 1
VGA 15-Pin D-Sub x 1
Composite (CVBS) BNC x 2
S-Video 4-Pin mini DIN x 1
Output Composite (CVBS) BNC x 2
External Control RS232 In 2.5 mm Phone Jack
Other Connectivity USB 2.0 p55-x1 (Service Port)
Audio Audio In Stereo Audio Jack (3.5 mm)
Stereo Audio Jack (RCA)
Audio Out Stereo Audio Jack (RCA)
Internal Speakers 2W x 2
Power Power Supply External
Power Requirements DC 12V, 2.5A
On Mode 18W (On)
Standby Mode < 0.5 W
Off Mode < 0.3 W
Glass Thickness 3.0 mm (0.12")
Reection Rate < 1%
Transmission Rate > 97%
MOHS Hardness 6
Pencil Hardness 9H
IK Rating IK07
Operating Conditions Temperature -5°C-45°C (32°F-104°F)
Humidity 10%-90% (non-condensing)
Transport/ Storage
Conditions
Temperature -20°C-60°C (-4°F-140°F)
Humidity 5%-95% (non-condensing)
Mounting VESA FPMPMI Yes (100 x 100 mm & 75 x 75 mm)
Stand Tilt 3° to 21°
Security Kensington Security Slot Yes
Dimensions w/o Base (W x H x D) 562.4 x 352.6 x 56.2 mm (22.1” x 13.9” x 2.2”)
w/Base (W x H x D) 562.4 x 392.8 x 196.0 mm (22.1” x 15.4” x 7.7”)
Packaging (W x H x D) 672.0 x 517.0 x 249.0 mm (26.5” x 20.4” x 9.8”)
Weight w/o Base 6.9 kg (15.3 lb)
w/Base 7.7 kg (17.0 lb)
Packaging 10.4 kg (23.0 lb)
Note:
♦ All specications are subject to change without prior notice.
