35
ADJUSTING THE LCD DISPLAY
5.3 Image Setting
1 920x1080 60Hz
BRIGHTNESS
C OLOUR TEMP.
IMAGE SETTING
A SPECT RATIO
PIP SETTING
ANTI-BURN-IN
OSD SETTING
AUDIO SETTING
SYSTEM 1
SYSTEM 2
ECOSMART SENSOR
INPUT SELECT
L ANGUAGE
INFORMATION
CONTRAST
SAT URATION
50
S HARPNESS
0
TINT
50
GAMMA
C OLOUR RANGE
2.0 2.2 2.4 S
N OISE REDUCTION
AUTO
LIMITED
P HASE
50
C LOCK
50
PICTURE MODE
CCTV
VIDEO
STANDARD
EXIT SELECT
ADJUST
LOW
MID
H IGH
OFF
H. POSITION
50
V. POSITION
50
FULL
1. Press the button to call out the OSD
window.
2. Select IMAGE SETTING menu, then
press the
u button.
3. Press the
p or q button to select an
option.
Item Function Operation Range
SHARPNESS
Adjusts the clarity and focus of the
screen image.
Press the
t or u button to
adjust the value.
0 to 100
SATURATION Adjusts the colour saturation.
TINT Adjusts the colour tint.
GAMMA
Adjusts the non-linear setting for
picture luminance and contrast.
Press the
t or u button to
select the setting.
2.0
2.2
2.4
S
INPUT
OUTPUT
INPUT
OUTPUT
INPUT
OUTPUT
INPUT
OUTPUT
Display Gamma 2.0 Display Gamma 2.2 Display Gamma 2.4 Display Gamma S
