69
CHAPTER 7: SPECIFICATIONS
7.1 Display Specifications
IFP6504P IFP7504P IFP8604P
Panel Panel Type LED-Backlit TFT LCD
(IPS Technology)
LED-Backlit TFT LCD
(IPS Technology)
LED-Backlit TFT LCD
(IPS Technology)
Panel Size 64.5" 74.5" 85.6"
Max. Resolution UHD 3840 x 2160 UHD 3840 x 2160 UHD 3840 x 2160
Pixel Pitch 0.372 mm 0.430 mm 0.494mm
Brightness 400 cd/m
2
400 cd/m
2
400 cd/m
2
Contrast Ratio 1200:1 1200:1 1200:1
Viewing Angle (H/V) 178°/178° 178°/178° 178°/178°
Display Colour 1.07G colors (10bits). 1.07G colors (10bits). 1.07G colors (10bits).
Response Time 5 ms 5 ms 5 ms
Surface Treatment Haze 25%, 2H, Anti-Glare Haze 25%, 3H, Anti-Glare Haze 25%, 3H, Anti-Glare
Frequency (H/V) H Freq. 30 kHz-135 kHz 30 kHz-135 kHz 30 kHz-135 kHz
V Freq. 30Hz-76Hz 30Hz-76Hz 30Hz-76Hz
Input HDMI 2.1 x 1 2.1 x 1 2.1 x 1
Type-C x 1 (PD:60W) x 1 (PD:60W) x 1 (PD:60W)
Output HDMI 2.1 x 1 2.1 x 1 2.1 x 1
External Control RS232 In 9-Pin D-Sub 9-Pin D-Sub 9-Pin D-Sub
LAN (RJ45) RJ45 x 2 RJ45 x 2 RJ45 x 2
Embedded System OS Android 13.0 Android 13.0 Android 13.0
CPU Cortex A76+A55 Cortex A76+A55 Cortex A76+A55
Memory 8G 8G 8G
Storage 128G 128G 128G
Other Connectivity USB USB 3.0 x 5 (Media Playback)
Type-C(PD:60W)
USB 3.0 x 5 (Media Playback)
Type-C(PD:60W)
USB 3.0 x 5 (Media Playback)
Type-C(PD:60W)
OPS Slot Yes Yes Yes
Audio Audio Out S/PDIF S/PDIF S/PDIF
Internal Speakers 15W x 2 15W x 2 15W x 2
Touch Screen Technology Infrared Touch Frame Infrared Touch Frame Infrared Touch Frame
Positional Accuracy ±1 mm ±1 mm ±1 mm
Panel Interface USB (Type-B) USB (Type-B) USB (Type-B)
Single-touch Plug &
Play
Windows 2000/XP/Vista/CE
6.0 macOS
Windows 2000/XP/Vista/CE
6.0 macOS
Windows 2000/XP/Vista/CE
6.0 macOS
Multi-touch Plug & Play 40 point touch for Windows
7/8/10/11
20 points for Android/Linux
(kernel 3.5 above)
Chrome 39 or above
40 point touch for Windows
7/8/10/11
20 points for Android/Linux
(kernel 3.5 above)
Chrome 39 or above
40 point touch for Windows
7/8/10/11
20 points for Android/Linux
(kernel 3.5 above)
Chrome 39 or above
Multi-touch Support by
Driver
20 point touch for macOS
(supported by UPDD driver)
20 point touch for macOS
(supported by UPDD driver)
20 point touch for macOS
(supported by UPDD driver)
Camera Resolution 8M 8M 8M
Pixel 3840x2106(30fps) 3840x2106(30fps) 3840x2106(30fps)
Microphone 8-Array 8-Array 8-Array
Power Power Requirements AC100~240, 50Hz~60Hz AC100~240, 50Hz~60Hz AC100~240, 50Hz~60Hz
On Mode 185W (On) 235W(On) 350W(On)
Standby Mode <0.5W <0.5W <0.5W
Off Mode 0W 0W 0W
Power Supply Internal Internal Internal
Glass Thickness 3.2 mm (0.13") 3.2 mm (0.13”) 3.2 mm (0.13”)
MOHS Hardness 5 5 5
Pencil Hardness 8H 8H 8H
IK Rating IK08 IK08 IK08
Gloss ≤0.3 um ≤0.3 um ≤0.3 um
Haze 3%~8% 3%~8% 3%~8%
Operating Conditions Temperature 0°C-40°C (32°F-104°F) 0°C-40°C (32°F-104°F) 0°C-40°C (32°F-104°F)
Humidity 20%-80% (non-condensing) 20%-80% (non-condensing) 20%-80% (non-condensing)
