EN 6
© Copyright LOTRONIC 2023
LED display instruction:
{INTR}{DMX}{APP}{SET}{SND}{SEL} for status identication.
• {INTR} Indicates that the xture is using the built-in effect. When the status ag is lit (INTR}
alone, it is the built-in effect play mode.
• {DMX} indicates that the xture is controlled by the DMX signal. The status ag is only bright
(DMX) for the standard DMX control mode
• {INTR} {DMX} is a simple DMX mode that calls the built-in scenario via DMX signals.
• {SET} indicates that the xture is in the system setup state.
• {SND} indicates that the motion of the pattern is controlled by the sound when the xture is in
the built-in mode.
• {SEL} In the set state, the indicator is lit to indicate that the current setting option is enabled.
{INTR} the state of the digital display section
• {AL} indicates the mix mode in the built-in mode (the scene play is extracted from each se-
quence).
• {P ###} Indicates the scene playback mode when the built-in mode is displayed. The displayed
value is the scene number.
• {SE ##} indicates the sequence playback mode when the built-in mode is displayed, and the dis-
played value is the sequence number.
{DMX} the digital display part state.
{INTR} + {DMX}the digital display part state.
• {A ###} Indicates the DMX address code for the xture.
{SET} the digital display part state.
• {SE ##} Indicates whether the digital display sequence is selected when the mixed mode of the
built-in mode is used.
(Note: {SEL} status ag indicates whether the sequence is selected.)
• {DR- ||} indicates the X mirror setting.
• {DR- =} represents the Y mirror setting.
• {DR- = ||} represents XY offset.
• {x ###} represents the X projection amplitude, the digital part is the full scale percentage value
(Note: {SEL} can be adjusted through the button on the board).
• {y ###} denotes the Y projection amplitude (Note: same as above).
• {r0FF} Indicates whether or not the remote control function is turned off.
The virtual remote control of the mobile phone APP is the same as that described in the previous
section.
Extinguished: After a few hours of inactivity, the digital part of the display will go out (Note: some
models do not have this function)
REMOTE CONTROL
Please operate the remote control within a distance of 6m and 30° between the remote and the
appliance. Aim the remote at the sensor. Remove all obstacles between the remote and the sensor.
The remote control might not work properly if the sensor is exposed to strong sunshine.
If the remote control doesn’t work properly, please check the batteries.
Installing the Batteries IN THE REMOTE CONTROL
• Place the remote face down on a at surface.
• Push the compartment cover into the direction of the arrow.
• Slide the battery compartment open.
• Remove the old battery and install the new one (CR2032) with the plus (+) symbol facing up.
• Gently slide the battery compartment closed. It locks automatically.
RECOMMENDATIONS FOR BATTERIES
This symbol indicates that used batteries should not be disposed of with household waste but deposed correctly in accordance with your
local regulations..
